LMS Series
Non-Contact Laser Distance Sensor — Up to 2,000 mm, IP67
Non-Contact Laser Distance Sensor — Up to 2,000 mm, IP67
The LMS Series uses a 940 nm VCSEL laser and time-of-flight principle to measure distances up to 2,000 mm without contact. The compact 12 mm body makes it suitable for tight installations. CANopen, MODBUS, and analog outputs cover all common industrial integration requirements. IP67 protection and a broad supply range (10–30 VDC) allow direct field installation.
Non-contact laser time-of-flight measurement — 940 nm VCSEL, Class 1 safe
Up to 2,000 mm user-selectable range — configure to application
Compact 12 mm body — fits tight installation spaces
CANopen and MODBUS fieldbus outputs — plus analog and switch
IP67 protection — fully sealed for field installation
No target reflector required — diffuse sensing on any surface
| Measuring Principle | Laser Time-of-Flight (940 nm VCSEL) |
| Range | Up to 2,000 mm (user selectable) |
| Body Diameter | 12 mm |
| Output | Analog, CANopen, MODBUS, Switch |
| IP Rating | IP67 |
| Supply Voltage | 10–30 VDC |
| Operating Temperature | −25°C to +70°C |
Specify output type on order. CANopen and MODBUS variants include digital process value; analog variants provide a voltage or current proportional to distance. Switch variant activates at a configurable distance threshold.
Contact us for the full technical drawing (PDF)
